Rigol
Rigol MSO7014
High quality 4 channel oscilloscope with 100 MHz Bandwidth, 10 GSa/s sample rate, up to 500 Mpts memory depth and a 25.7 cm touchdisplay 1024x600 pixel. Including integrated 16 channel logic analyser. Upgradable to a 2 channel 25 MHz waveform generator.
100 MHz Larghezza di banda
4 Numero di canali analogici
16 Canali digitali
10 GSa/s Frequenza di campionamento massima
100 Mpts Profondità di memoria
| Attributo | Valore |
|---|---|
| Larghezza di banda | 100 MHz |
| Numero di canali analogici | 4 |
| Canali digitali | 16 |
| Frequenza di campionamento massima | 10 GSa/s |
| Profondità di memoria | 100 Mpts |
| Risoluzione verticale | 8 bit (12 bit in modalità ad alta risoluzione) |
| Dimensione del display | 10,1 pollici touchscreen capacitivo |
| Frequenza di aggiornamento della forma d'onda | 600.000 forme d'onda al secondo |
| Interfacce di connettività | USB Host, USB Device, LAN (LXI), HDMI |
| Generatore di forme d'onda integrato | 25 MHz, 2 canali |
| Model | MSO7014 |
|---|
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1" display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
