Keithley 2260B-800-2
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 800 V |
| Output Current | 0 – 2 A |
| Output Power | 1200 W |
| Line Regulation (Voltage) | ≤0.01% + 10 mV |
| Load Regulation (Voltage) | ≤0.01% + 10 mV |
| Output Voltage Ripple & Noise (RMS) | ≤200 mV |
| Programming Interface | USB, GPIB, RS-232, Analog |
| AC Input Voltage | 100/120/220/240 VAC ±10%, Single Phase |
| Operating Temperature | 0°C to 50°C |
| Dimensions (W × H × D) | 425 mm × 88 mm × 600 mm (2U, Full Rack) |
Keithley 2260B-800-2 Options:
- 2260B-800-2 - 2260-001 - Accessory Kit: Analog control mating connector, pins, cover, and ground wire
- 2260B-800-2 - 2260-002 - Simple IDC Tool
- 2260B-800-2 - 2260-003 - Contact Removal Tool
- 2260B-800-2 - 2260-004 - Basic Accessories Kit: Air filter, analog connector cover, analog control lock lever, M8-size output terminal bolts, washers and screws, and M4-size output terminal screws with washers
- 2260B-800-2 - 2260-005 - Cable, 0.5m (1.6 ft.), to connect two Series 2260B power supplies in series
- 2260B-800-2 - 2260-006 - Cable, 0.5m (1.6 ft.), to connect two Series 2260B power supplies in parallel
- 2260B-800-2 - 2260B-007 - Cable, 0.5m (1.6 ft.), to connect three Series 2260B power supplies in parallel
- 2260B-800-2 - 2260B-GPIB-USB - GPIB-to-USB Adapter: Provides a GPIB interface for the Series 2260B power supplies
- 2260B-800-2 - 2260B-EXTERM - Extended Terminal: Test Leads, 0.7m (28 in.), and terminal box to bring outputs to the front of the instrument or another location. Magnetic base attaches to side of instrument
- 2260B-800-2 - 2260B-RMK-JIS - Rack Mount Kit (JIS racks)
- 2260B-800-2 - 2260B-RMK-EIA - Rack Mount Kit (EIA racks)
- 2260B-800-2 - -EW - 3-year factory warranty extended to 1 additional year from date of shipment
- 2260B-800-2 - -5Y-EW - 3-year factory warranty extended to 5 years from date of shipment
- 2260B-800-2 - C/-3Y-STD - KeithleyCare 3 Year Standard Calibration Plan
- 2260B-800-2 - C/-3Y-DAT - KeithleyCare 3 Year Calibration with Data Plan
- 2260B-800-2 - C/-5Y-STD - KeithleyCare 5 Year Standard Calibration Plan
- 2260B-800-2 - C/-5Y-DAT - KeithleyCare 5 Year Calibration with Data Plan
| Model | 2260B-800-2 |
|---|
The Keithley 2260B-800-2 is a programmable DC power supply offering a wide output range of 0–800 V and 0–2.88 A with 720 W power. It features programmable rise/fall times, internal resistance up to 277.8Ω, fast 1ms transient recovery, and analog control via voltage or resistance. Interfaces include USB, LAN, and optional GPIB.
This supply simulates battery behavior and can superimpose AC signals on DC output. It supports test sequences, fast discharge, and serial/parallel configuration up to 160V/216A for various testing applications including LED, automotive, and battery testing.
Testwall can supply the used Keithley 2260B-800-2, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2260B-800-2.
