Keithley 2268-100-8
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 100 V |
| Output Current | 0 – 8 A |
| Output Power | 800 W |
| Number of Outputs | 1 |
| Line Regulation (Voltage) | ≤ 0.01% + 3 mV |
| Load Regulation (Voltage) | ≤ 0.01% + 3 mV |
| Ripple and Noise (RMS) | ≤ 15 mV |
| Programming Interface | RS-232, GPIB (IEEE-488), Analog |
| Input Voltage | 100 – 240 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
Keithley 2268-100-8 Options:
- 2268-100-8 - EW - 1 additional year of factory warranty
- 2268-100-8 - 5Y-EW - 2 additional years of factory warranty beyond the standard 3-year warranty
- C/2268-100-8 - 3Y-STD - 3 calibrations within 3 years of purchase
- C/2268-100-8 - 3Y-DATA - 3 (ANSI-Z540-1 compliant) calibrations within 3 years of purchase
- C/2268-100-8 - 5Y-STD - 5 calibrations within 5 years of purchase
- C/2268-100-8 - 5Y-DATA - 5 (ANSI-Z540-1 compliant) calibrations within 5 years of purchase
| Model | 2268-100-8 |
|---|
The Keithley 2268-100-8 DC Power Supply features a compact design delivering 800W with high power density, offering both analog/digital control and multiple digital interfaces like LAN, USB, GPIB, RS-232, and RS-485. It supports CV, CC, and constant power modes with soft-start and efficient performance.
It includes 15V and 5V auxiliary outputs for device signaling/control, with auto-sequence programming to streamline command execution directly from internal memory, reducing PC communication delays.
Testwall can supply the used Keithley 2268-100-8, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2268-100-8.
