Keithley 7002-HD-MTX1
Differential 6x32 Matrix Card
High Density Matrix Card for 7002 Switch Mainframe Matrix Configuration
Up to 1800 two-wire crosspoints (60 rows × 30 columns) Channel Capacity
300 V DC or RMS Maximum Voltage
1 A per channel Maximum Current
60 W per channel Maximum Power
| Attribute | Value |
|---|---|
| Matrix Configuration | High Density Matrix Card for 7002 Switch Mainframe |
| Channel Capacity | Up to 1800 two-wire crosspoints (60 rows × 30 columns) |
| Maximum Voltage | 300 V DC or RMS |
| Maximum Current | 1 A per channel |
| Maximum Power | 60 W per channel |
| Contact Resistance | Less than 1 Ω initial |
| Insulation Resistance | Greater than 10⁹ Ω at 500 V DC |
| Relay Type | Reed relay switching |
| Compatible Mainframe | Keithley 7002 High Density Switch Mainframe |
| Connection Interface | High density card slot interface compatible with 7002 mainframe backplane |
| Model | 7002-HD-MTX1 |
|---|
The Keithley 7002-HD-MTX1 is a differential 6x32 matrix card offering 192 crosspoints with high-density switching. It enables precise signal routing with low thermal EMF and minimal crosstalk, ideal for complex measurement configurations.
Designed for seamless integration with Keithley switching systems, it supports automated test setups requiring differential signaling paths.
Testwall can supply the used Keithley 7002-HD-MTX1 Differential 6x32 Matrix Card, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 7002-HD-MTX1 Differential 6x32 Matrix Card.
