Keithley 7072-HV
Semiconductor Matrix Card, 8x12, High Voltage
8 channels per card Number of Channels
1100 V DC Maximum Voltage
100 mA per channel Maximum Current
Less than 2 Ω initial Contact Resistance
Greater than 10^9 Ω at 500 V DC Insulation Resistance
| Attribute | Value |
|---|---|
| Number of Channels | 8 channels per card |
| Maximum Voltage | 1100 V DC |
| Maximum Current | 100 mA per channel |
| Contact Resistance | Less than 2 Ω initial |
| Insulation Resistance | Greater than 10^9 Ω at 500 V DC |
| Compatible Mainframe | Keithley 707B Switching Matrix Mainframe |
| Switch Configuration | Matrix (8 rows × 12 columns) |
| Relay Type | Reed relays |
| Operating Temperature Range | 0°C to 50°C |
| Primary Application | High-voltage semiconductor device characterization and wafer-level testing |
Keithley 7072-HV Options:
- 7072-HV - 7072-HV-3Y-EW - 1-year factory warranty extended to 3 years from date of shipment
| Model | 7072-HV |
|---|
The Keithley 7072-HV is a high-voltage 2x8 matrix switch card that supports up to 1000V switching, ideal for testing high-impedance and high-voltage devices with superior isolation.
It features low leakage, minimal dielectric absorption, and integrates seamlessly with 707 and 708 mainframes.
Testwall can supply the used Keithley 7072-HV, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 7072-HV.
