Keysight (Agilent) 34942A
| Attribute | Value |
|---|---|
| Form Factor | Plug-in Module for 34980A Multifunction Switch/Measure Unit |
| Module Type | Quad 4x8 Two-Wire Matrix Switch Module |
| Matrix Configuration | 4 x 8 (4 rows x 8 columns) per bank, 4 banks total |
| Total Crosspoints | 128 crosspoints (32 per bank) |
| Maximum Voltage | 300 V DC or AC RMS |
| Maximum Current | 1 A per channel |
| Maximum Power Switching | 50 VA per channel |
| Relay Type | Reed Relays |
| Frequency Range | DC to 100 MHz (–3 dB) |
| Contact Resistance | Less than 1 Ohm initial |
| Model | 34942A |
|---|
The Keysight (Agilent) 34942A is a quad 4-channel, 75 Ohm RF multiplexer module supporting DC to 1.5 GHz frequencies. It features 75 Ohm mini SMB connectors, high isolation, low VSWR, and allows bi-directional switching of broadband signals with up to 10W switching capacity.
This module fits into the Keysight 34980A mainframe and enables cascading of up to 97 RF channels. Each multiplexer is independently isolated to prevent ground loops and ensure signal integrity across multiple configurations.
Testwall can supply the used Keysight (Agilent) 34942A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 34942A.
