Keysight (Agilent) 44478A
| Attribute | Value |
|---|---|
| Module Type | Microwave Switch Module |
| Frequency Range | DC to 26.5 GHz |
| Switch Configuration | Dual 1x4 (SP4T) |
| Connector Type | SMA (female) |
| Insertion Loss | 3.5 dB maximum at 26.5 GHz |
| Isolation | 60 dB minimum at 1 GHz, 40 dB minimum at 26.5 GHz |
| VSWR | 1.9:1 maximum at 26.5 GHz |
| Compatible Mainframe | Keysight 44470A Series Switch Mainframe |
| Number of Channels | 8 channels (4 per switch) |
| Operating Temperature | 0°C to 55°C |
| Model | 44478A |
|---|
The Keysight (Agilent) 44478A is a Dual 1x4 RF Multiplexer Module that supports broadband operation up to 1 GHz, ideal for routing high-frequency signals with minimal loss. Its dual 1x4 multiplexer design offers independent signal paths, and low insertion loss ensures accurate signal transmission. Each channel is terminated with 50-ohm impedance, supporting a wide variety of test scenarios.
Perfect for automated test environments, the 44478A allows multiple signal sources to be routed to a common output, streamlining testing procedures. It is a plug-in module for Keysight (Agilent) mainframes, enhancing system scalability.
Testwall can supply the used Keysight (Agilent) 44478A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 44478A.
