Keysight (Agilent) 8565E
| Attribute | Value |
|---|---|
| Frequency Range | 9 kHz to 50 GHz |
| Display Average Noise Level | -148 dBm (nominal) at 1 GHz, 10 Hz RBW |
| Phase Noise | -98 dBc/Hz at 1 GHz carrier, 10 kHz offset |
| Amplitude Accuracy | ±0.5 dB absolute amplitude accuracy |
| Resolution Bandwidth (RBW) | 1 Hz to 5 MHz in 1-3-10 sequence |
| Dynamic Range | >90 dB (third-order intermodulation free dynamic range) |
| Input Attenuator Range | 0 to 70 dB in 10 dB steps |
| Sweep Time | 50 ms to 100 s (swept spans); 1 ms minimum (zero span) |
| RF Input Connector | 2.4 mm (f) connector, 50 Ω impedance |
| Power Requirements | 100–240 V AC, 48–66 Hz, 350 W maximum |
Keysight (Agilent) 8565E 50GHz Spectrum Analyser Options:
- 8565E - 001 - Second If Output; Rear Panel Connector
- 8565E - 002 - Tracking Generator (8560E)
- 8565E - 005 - Add Alternate Sweep Output
- 8565E - 006 - Down To 30HZ Frequency Extension (8563/4/5E)
- 8565E - 007 - Digitised Fast Sweeps
- 8565E - 008 - Add Signal Identification
- 8565E - 026 - Apc 3.5 Input Connector (8563E)
- 8565E - 042 - Protective Carry Case/Backpack
- 8565E - 103 - Delete Precision Frequency Reference, 1HZ And 3HZ Rbw
- 8565E - 104 - Delete 85620A Mass Memory Module
- 8565E - 908 - Rackmount Kit Without Handles
- 8565E - 909 - Rackmount Kit With Handles And Flanges
- 8565E - B70 - Benchlink Spectrum Analyzer S/W
- 8565E - E35 - Acpr Test Set
- 8565E - H35 - Firmware Upgrade For E35
- 8565E - J67 - Bundle Options Uk6,006 & 007
- 8565E - K35 - System With Cdma Test Set Attached
| Model | 8565E |
|---|
The Keysight (Agilent) 8565E Spectrum Analyzer covers a frequency range from 9 kHz to 50 GHz with a low noise floor of -147 dBm and RBW of 1 Hz to 2 MHz. It features low phase noise, wide dynamic range, and a precision 1 Hz counter resolution. With digitally implemented RBW and a narrow 5:1 shape factor, it offers high-speed sweeps and detailed signal resolution in harsh environments.
It supports ACP measurements, time-gated signal analysis, and features AMPCOR for amplitude correction. Ideal for testing digital modulation systems like GSM, DECT, and W-CDMA with a dynamic range of 70 dB.
Testwall can supply the used Keysight (Agilent) 8565E, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 8565E.
