Keysight (Agilent) M9484C
| Attribute | Value |
|---|---|
| Modulation | I/Q |
| Frequency Resolution | 0.00001 Hz |
| Non-Harmonics | -60 dBc, 10 MHz to 7.25 GHz |
| Switching Speed | 3.0 ms |
| Interfaces | GPIB, LAN |
| Frequency Range | 9 kHz to 6, 8.5, 14, 21.6, 31.8, 44 or 54 GHz |
| Output Power | -135 to +20 dBm settable |
| SSB Phase Noise | -144 dBc/Hz at 1 GHz, 10 kHz offset |
| Level Accuracy | ±1.1 to ±1.7 dB, 12 MHz to 20 GHz (spec.) |
| Harmonics | -30 dBc up to 7.25 GHz at +10 dBm |
| Modulation Bandwidth | 160 MHz, 250 MHz (B2X), 500 MHz (B5X), 1 GHz (R10), 2.5 GHz (R25) |
| RF Output Connector | Type-N female (506/508), 3.5 mm male (514/520), 1.85 mm male (532/544/554) |
| Dimensions | 461.5 × 193 × 635 mm |
| Weight | 27.9 to 35.3 kg |
The Keysight (Agilent) M9484C is a high-performance vector signal generator available in frequency options of 6, 8.5, 14, 20, 31.8, 44, or 54GHz. It delivers exceptional modulation accuracy, high output power, and advanced baseband capabilities, ideal for wideband and multichannel signal simulation. Designed for scalability and compatibility with PXIe, it supports demanding RF testing environments.
Ideal for 5G, satellite, and aerospace applications, the M9484C supports complex signal generation with seamless integration and consistent output performance across all frequency bands.
Testwall can supply the used Keysight (Agilent) M9484C, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) M9484C.
Options and configurations
- Frequency Range: 9 kHz to 6, 8.5, 14, 21.6, 31.8, 44 or 54 GHz (Opt. 506/508/514/520/532/544/554)
- Output Power: -135 to +20 dBm settable (+30 dBm with Opt. 1EA/1EB/1EC)
- SSB Phase Noise: -144 dBc/Hz at 1 GHz, 10 kHz offset (Opt. ST6)
- Modulation Bandwidth: 160 MHz (Opt. B1X), 250 MHz (B2X), 500 MHz (B5X), 1 GHz (R10), 2.5 GHz (R25)
