Keysight (Agilent)
Keysight (Agilent) N1032A
90/120 GHz Optical Module For DCA-X Mainframe
DC to 40 GHz Frequency Range
2.92 mm (K-type) Connector Type
2-Port Number of Ports
50 Ohm Impedance
Less than 1.5 dB at 40 GHz Insertion Loss
| Attribute | Value |
|---|---|
| Frequency Range | DC to 40 GHz |
| Connector Type | 2.92 mm (K-type) |
| Number of Ports | 2-Port |
| Impedance | 50 Ohm |
| Insertion Loss | Less than 1.5 dB at 40 GHz |
| Return Loss | Greater than 20 dB |
| Power Handling | 1 W Average |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Coupling Factor | 10 dB ± 1.0 dB |
| Model | N1032A |
|---|
Keysight (Agilent) N1032A 90/120 GHz Optical Module For DCA-X Mainframe Description: 90GHz optical channel (standard) Optional 120GHz optical channel Low jitter: as low as 90 fs Ideal for analyzing 112 GBd (224 Gbps) optical signals Requires DCA-X mainframe Keysight (Agilent) N1032A 90/120 GHz Optical Module For DCA-X Mainframe
