Keysight (Agilent)
Keysight (Agilent) N4432D
300kHz to 18GHz ECAL Module 4-Port
10 MHz to 26.5 GHz Frequency Range
4-Port Number of Ports
2.92 mm (K) Connectors Connector Type
50 Ohm Impedance
Electronic Calibration (ECal) Calibration Type
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 26.5 GHz |
| Number of Ports | 4-Port |
| Connector Type | 2.92 mm (K) Connectors |
| Impedance | 50 Ohm |
| Calibration Type | Electronic Calibration (ECal) |
| Insertion Loss | Less than 3 dB typical |
| Port Match (Return Loss) | Greater than 30 dB typical |
| Crosstalk Isolation | Greater than 70 dB typical |
| Compatible Instruments | Keysight PNA, PNA-L, PNA-X, ENA Series Network Analyzers |
| Operating Temperature | 0°C to 55°C |
| Model | N4432D |
|---|
Keysight (Agilent) N4432D 300kHz to 18GHz ECAL Module 4-Port Description: Frequency Range: DC/300 kHz to 18 GHz Precision 4-port RF ECal module with high accuracy Fast, easy, and accurate full 4-ports calibration Direct control from Keysight vector network analyzers via USB Keysight (Agilent) N4432D 300kHz to 18GHz ECAL Module 4-Port
