Keysight (Agilent)
Keysight (Agilent) N4692D
10MHz to 40GHz ECAL Module 2-Port
0.01 MHz to 67 GHz Frequency Range
2-Port Number of Ports
1.85 mm (V-connector) Connector Type
Up to 105 dB Dynamic Range
S-parameters (S11, S21, S12, S22) Measurement Parameters
| Attribute | Value |
|---|---|
| Frequency Range | 0.01 MHz to 67 GHz |
| Number of Ports | 2-Port |
| Connector Type | 1.85 mm (V-connector) |
| Dynamic Range | Up to 105 dB |
| Measurement Parameters | S-parameters (S11, S21, S12, S22) |
| Compatible Instruments | PNA, PNA-X, PNA-L Series Vector Network Analyzers |
| Interface Type | Electronic Calibration Module (ECal) |
| Calibration Standards | Open, Short, Load, Thru (OSLT) |
| Operating Temperature | 0°C to 55°C |
| USB Interface | USB 2.0 for connection to VNA |
| Model | N4692D |
|---|
Keysight (Agilent) N4692D 10MHz to 40GHz ECAL Module 2-Port Description: Frequency Range: 10 MHz to 40 GHz Precision 2-port microwave ECal module with high accuracy USB interface for direct control with PNA and ENA series VNAs Reliable solid-state switching Fast & easy calibration Keysight (Agilent) N4692D 10MHz to 40GHz ECAL Module 2-Port
