Keysight (Agilent)
Keysight (Agilent) N4696D
300kHz to 18GHz ECAL Module 7mm 2 Port
DC to 67 GHz Frequency Range
1.85 mm (V-connector) Connector Type
< 1.5 dB typical Insertion Loss
> 20 dB typical Return Loss
50 Ohm Impedance
| Attribute | Value |
|---|---|
| Frequency Range | DC to 67 GHz |
| Connector Type | 1.85 mm (V-connector) |
| Insertion Loss | < 1.5 dB typical |
| Return Loss | > 20 dB typical |
| Impedance | 50 Ohm |
| Device Type | Calibration Module / Electronic Calibration (ECal) |
| Number of Ports | 2-Port |
| Compatible Instruments | Keysight PNA, PNA-X, PNA-L, and ENA Series Vector Network Analyzers |
| Operating Temperature | 0°C to 55°C |
| Interface | USB |
| Model | N4696D |
|---|
Keysight (Agilent) N4696D 300kHz to 18GHz ECAL Module 7mm 2 Port Description: Frequency Range: 300kHz to 18 GHz Full two-port calibration with a single connection USB interface for direct control with PNA and ENA series VNAs Reliable solid-state switching 7mm connectors Keysight (Agilent) N4696D 300kHz to 18GHz ECAL Module 7mm 2 Port
