Keysight (Agilent) U2723A
| Attribute | Value |
|---|---|
| Output Channels | 3 Channels (2 programmable + 1 fixed) |
| Voltage Output Range | 0 to 20 V (Channels 1 & 2), Fixed 5 V (Channel 3) |
| Current Output Range | 0 to 120 mA (Channels 1 & 2), Up to 1 A (Channel 3) |
| Voltage Programming Accuracy | 0.03% + 3 mV |
| Current Programming Accuracy | 0.1% + 0.05 mA |
| Interface | USB 2.0 (Full Speed) |
| Form Factor | USB Modular Instrument (U2700 Series) |
| Operating Temperature | 0°C to 55°C |
| Programming Language / Software Compatibility | IVI-COM, IVI-C, LabVIEW, MATLAB, Agilent VEE |
| Power Supply | Bus-powered via USB |
Keysight (Agilent) U2723A Options:
- U2941A - U2941A - Parametric test fixture
- U2942A - U2942A - Parametric Measurement Manager Pro software
- U2722P - U2722P - U2722A USB modular source measure unit and U2942A Parametric Measurement Manager Pro bundle (only available in Europe and Asia, excluding Japan)
- U2723P - U2723P - U2723A USB modular source measure unit and U2942A Parametric Measurement Manager Pro bundle (only available in Europe and Asia, excluding Japan)
- U2921A - 101 - USB secure cable, 2 m
- U2941A - 101 - Pin plug-to-pin plug cable, black
- U2941A - 102 - Pin plug-to-pin plug cable, red
- U2941A - 103 - Pin plug-to-pin plug cable, blue
- U2941A - 104 - Pin plug-to-miniature clip cables, black
- U2941A - 105 - Pin plug-to-miniature clip cables, red
- U2941A - 106 - Pin plug-to-miniature clip cables, blue
- U2941A - 107 - BNC to two-wire, 1 m
- U2941A - 201 - Assembly PTFE plate – Insulation board with minimal leakage current; suitable for extremely low-current measurement
- U2941A - 202 - 28-pin dual-in-line package (DIP) socket module – Lever actuated zero insertion force (ZIF) socket
- U2941A - 203 - 0.1-inch universal socket module – 0.1-inch pitch; suitable for virtually any device such as components, DIP IC or small scale circuit
- U2941A - 204 - 0.075-inch universal socket module – 0.075-inch pitch; suitable for virtually any device such as components, DIP IC or small scale circuit
- U2941A - 205 - 0.05-inch universal socket module – 0.05-inch pitch; suitable for any device such as components, DIP IC or small scale circuit
| Model | U2723A |
|---|
The Keysight (Agilent) U2723A is a 3-channel USB Modular Source Measure Unit offering ±20 V, ±120 mA with high current sensitivity of 100 pA and 16-bit resolution. It features embedded test scripts per channel, a 4-quadrant operation, and allows series or parallel connection for up to 60 V/360 mA. The unit includes Agilent Measurement Manager software, USB 2.0 interface, and supports modular expansion for flexible test setups.
Ideal for automated testing, it supports various programming environments and includes tools like Command Logger and Code Converter for efficient configuration and scripting.
Testwall can supply the used Keysight (Agilent) U2723A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) U2723A.
