Keysight (Agilent) 16602A
102-Channel Logic Analyser
102 Channels Channel Count
235 MHz Maximum State Acquisition Speed
1 GHz (half channel), 500 MHz (full channel) Maximum Timing Acquisition Speed
64K samples per channel (state), 128K samples per channel (timing) Memory Depth
1.5 ns Minimum Detectable Glitch Width
| Attribute | Value |
|---|---|
| Channel Count | 102 Channels |
| Maximum State Acquisition Speed | 235 MHz |
| Maximum Timing Acquisition Speed | 1 GHz (half channel), 500 MHz (full channel) |
| Memory Depth | 64K samples per channel (state), 128K samples per channel (timing) |
| Minimum Detectable Glitch Width | 1.5 ns |
| Threshold Voltage Range | -6.0 V to +6.0 V, adjustable in 50 mV increments |
| Setup/Hold Time | Adjustable in 500 ps increments |
| Module Compatibility | Keysight 16700 Series Logic Analysis System Mainframe |
| Number of Pods | 9 Pods (102 data channels + clock channels) |
| Input Impedance | 100 kΩ ± 2% in parallel with 8 pF |
| Model | 16602A |
|---|
The Keysight (Agilent) 16602A is a 102-channel logic analysis system with 1 slot mainframe, multi-window interface, setup assistant, and 100 MHz max state clock. It supports on-chip emulation, time-correlated views, and has a max timing rate of 125 MHz (250 MHz in half-channel mode).
It includes 64 KB memory/channel (128 KB half mode), 12-level trigger, 10 pattern recognizers, and connectivity through Ethernet and IEEE802.3 ports.
Testwall can supply the used Keysight (Agilent) 16602A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 16602A.
