Keysight (Agilent) 4342A
| Attribute | Value |
|---|---|
| Measurement Function | Q Factor Measurement |
| Frequency Range | 22 MHz to 70 MHz |
| Q Measurement Range | 5 to 1000 |
| Inductance Measurement Range | 0.1 µH to 100 mH |
| Capacitance Measurement Range | 1 pF to 500 pF |
| Resistance Measurement Range | 0 to 10 MΩ |
| Oscillator Output Level | Approximately 100 mV (rms) across the test terminals |
| Power Requirements | 100/120/220/240 VAC, 50/60 Hz, 40 VA maximum |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Dimensions (W x H x D) | 213 mm x 133 mm x 375 mm (8.4 in x 5.2 in x 14.8 in) |
Keysight Technologies 4342A Options:
- 4342A - Opt 001 - Frequency Range (10 kHz - 32 MHz)
- 4342A - Opt 910 - Extra Manual
| Model | 4342A |
|---|
The Keysight (Agilent) 4342A Q Meter offers direct-reading expanded scale for Q values ranging from 5 to 1000, with precision resolution for small variations. It features a solid-state design eliminating fragile thermocouple parts, measuring dissipation factor and dielectric constant in insulating materials. Key specifications include a frequency range of 22 kHz to 70 MHz, capacitor range of 25 to 470 pF, and inductance range from 0.09 µH to 1.2 H.
It supports measurements of RF resistance, reactance, coupling coefficient, mutual inductance, and transformer frequency response, with automatic display of frequency and meter scales.
Testwall can supply the used Keysight (Agilent) 4342A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 4342A.
