Keysight (Agilent)
Keysight (Agilent) 54600
100 MHz Bandwidth
2 Number of Channels
20 MSa/s Sample Rate
2 mV/div to 5 V/div Vertical Sensitivity
8 bits Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 100 MHz |
| Number of Channels | 2 |
| Sample Rate | 20 MSa/s |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Vertical Resolution | 8 bits |
| Time Base Range | 5 ns/div to 5 s/div |
| Input Impedance | 1 MΩ ± 2% in parallel with 13 pF ± 3 pF |
| Display Type | Built-in CRT display |
| Trigger Types | Edge, TV, Pattern |
| Maximum Input Voltage | 300 V (CAT II) |
Keysight Technologies 54600 Options:
- 54600 - Option 003 - Shielding Option for use in severe environments or with sensitive devices under test – shields both ways (in and out): RS-03 Magnetic interface shielding added to CRT, and RE-02 display shield added to CRT to reduce radiated interference
- 54600 - Option 1CM - Rackmount kit (same as 1186A)
- 54600 - A6J - ANSI/NSCL Z540 calibration with test data (replaces 1BP)
- 54600 - R-50C-011-3 - 3-years of return-to-Agilent inclusive calibration service
- 54600 - R-50C-013-3 - 3-years of return-to-Agilent inclusive plus calibration service
- 54600 - R-50C-011-5 - 5-years of return-to-Agilent inclusive calibration service
- 54600 - R-50C-013-5 - 5-years of return-to-Agilent inclusive plus calibration service
- 54600 - R-51B-001-3C - 1-year return-to-Agilent warranty, extended to 3-years
- 54600 - R-51B-001-5C - 1-year return-to-Agilent warranty, extended to 5-years
- 54600 - ABA - Manual option: English
- 54600 - ABJ - Manual option: Japanese
- 54600 - AB2 - Manual option: Simplified Chinese
| Model | 54600 |
|---|
The Keysight (Agilent) 54600 is a 2-channel, 100 MHz analog oscilloscope offering high-fidelity waveform visualization with vertical sensitivity from 2 mV/div to 5 V/div. Its bright CRT display and analog trace response provide rapid diagnostics with stable triggering and a rise time of ≤ 3.5 ns. Equipped with a dual timebase, edge/pulse/video triggering, and 1 MΩ input impedance, it ensures ease of operation through traditional rotary controls.
Ideal for educational labs, circuit servicing, and R&D debugging, it supports accurate signal timing and fault isolation.
Testwall can supply the used Keysight (Agilent) 54600, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54600.
