Keysight (Agilent)
Keysight (Agilent) 54641A
350 MHz Bandwidth
2 Analog Channels Number of Channels
2 GSa/s Sample Rate
2 Mpts per channel Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 350 MHz |
| Number of Channels | 2 Analog Channels |
| Sample Rate | 2 GSa/s |
| Memory Depth | 2 Mpts per channel |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Input Impedance | 1 MΩ ± 1% in parallel with 13 pF ± 2 pF |
| Display | 6.3-inch color LCD display |
| Trigger Types | Edge, Glitch, Pattern, TV, CAN, LIN, Duration, Sequence |
Keysight Technologies 54641A Options:
- 54641A - 003 - Shielding Option for use in severe environments or with sensitive devices under test – shields both ways (in and out): RS-03 Magnetic interface shielding added to CRT, and RE-02 display shield added to CRT to reduce radiated interference
- 54641A - 1CM - Rackmount kit (same as 1186A)
- 54641A - A6J - ANSI/NSCL Z540 calibration with test data (replaces 1BP)
- 54641A - W32 - 3-year, customer-return calibration service
- 54641A - W34 - 3-year, customer-return standard comp cal service
- 54641A - W50 - Additional 2-year warranty (5 year total)
- 54641A - W52 - 5-year, customer-return calibration service
- 54641A - W54 - 5-year, customer-return standard comp cal service
- 54641A - ABA - Manual Option: English
- 54641A - ABJ - Manual Option: Japanese
- 54641A - AB2 - Manual Option: Simplified Chinese
| Model | 54641A |
|---|
The Keysight (Agilent) 54641A is a 350 MHz, 2-channel oscilloscope offering 2 GSa/s sample rate and 8 MB deep memory with MegaZoom technology, enabling detailed signal analysis over extended time windows.
It supports advanced triggering (I²C, SPI, LIN, CAN, USB), and features a high-definition display with 32-level intensity grading and 25 million vectors/sec for sharp waveform rendering.
Testwall can supply the used Keysight (Agilent) 54641A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54641A.
