Keysight (Agilent) 6205C
| Attribute | Value |
|---|---|
| Output Voltage | 0 to 100 V DC |
| Output Current | 0 to 0.2 A |
| Output Power | 20 W |
| Voltage Regulation (Line) | 0.01% + 2 mV |
| Current Regulation (Line) | 0.01% + 250 µA |
| Ripple and Noise (Voltage, RMS) | 0.35 mV RMS |
| Ripple and Noise (Current, RMS) | 250 µA RMS |
| Input Voltage | 115/230 V AC, 48-66 Hz |
| Operating Temperature | 0°C to 55°C |
| Dimensions (W x H x D) | 133 mm x 104 mm x 368 mm |
Keysight Technologies 6205C Options:
- 6205C - 010 - Overvoltage Protection for HP 6205C
- 6205C - 028 - 230 Vac ±10%, Single-Phase Input
- 6205C - 040 - Resistance Programming Interface
- 6205C - 910 - Additional operating and service manual
- 6205C - OE3 - 230 Vac ±10%, 47- to 63-Hz Input
- 6205C - OE9 - 100 Vac ±10%, 47- to 63-Hz Input
| Model | 6205C |
|---|
The Keysight (Agilent) 6205C dual-output power supply features precision 10-turn output voltage controls, dual range outputs, and selectable high/low output voltage ranges. It supports output 1 and 2 configurations of 0–20 V at 0–0.6 A or 0–40 V at 0–0.3 A, with ripple and noise as low as 200 µV rms and 1 mV peak-to-peak. Auto-tracking and volt-ampere metering are included for enhanced usability.
Ideal for laboratory and bench use, the 6205C offers stable voltage supply across a range of temperatures from 0 to 55°C, with load regulation of 0.01% + 4 mV and flexible front/rear terminals.
Testwall can supply the used Keysight (Agilent) 6205C, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 6205C.
