Keysight (Agilent)
Keysight (Agilent) 6625A
50V 2A Dual Output Power Supply
2 Output Channels
0 to 50V per channel Output Voltage Range
0 to 2A per channel Output Current Range
10 mV Programming Resolution (Voltage)
1 mA Programming Resolution (Current)
| Attribute | Value |
|---|---|
| Output Channels | 2 |
| Output Voltage Range | 0 to 50V per channel |
| Output Current Range | 0 to 2A per channel |
| Programming Resolution (Voltage) | 10 mV |
| Programming Resolution (Current) | 1 mA |
| Interface | GPIB (IEEE-488) |
| Readback Accuracy (Voltage) | ±(0.1% + 50 mV) |
| Readback Accuracy (Current) | ±(0.2% + 5 mA) |
| Power Rating | 200W total output power |
| Form Factor | Mainframe-based (HP/Agilent 66xx Series compatible) |
Keysight Technologies 6625A Options:
- 6625A - Opt 100 - 87 to 106 Vac, 47 to 66 Hz Input, 6.3 A (Japan only)
- 6625A - Opt 120 - 104 to 127 Vac, 47 to 63 Hz
- 6625A - Opt 220 - 191 to 233 Vac, 47 to 66 Hz, 3.0 A
- 6625A - Opt 240 - 209 to 250 Vac, 47 to 66 Hz, 3.0 A
- 6625A - Opt 750 - Relay Control and DFI/RI
- 6625A - Opt S50 - Similar to option 750, however the remote inhibit does not latch
- 6625A - Opt 908 - Rack-mount Kit (p/n 5062-3977)
- 6625A - Opt 909 - Rack-mount Kit w/Handles (p/n 5063-9221)
- 6625A - Opt 0L2 - Extra Standard Documentation Package
- 6625A - Opt 0B3 - Service Manual
- 6625A - Opt 0B0 - No documentation package
| Model | 6625A |
|---|
The Keysight (Agilent) 6625A is a precision dual-output GPIB power supply delivering 25W and 50W outputs in a compact 3U chassis. Each output supports dual-range operation with voltage spans from 0–50V and current up to 2A. Programming accuracy reaches as low as 1.5 mV + 0.016% for voltage and 15 µA + 0.04% for current. Ripple is kept minimal at 500 µV RMS and 1 mA RMS for stable operation. Built-in measurement and safety features enhance control, precision, and device-under-test protection.
Designed for test environments requiring high accuracy and low noise, it supports system automation and helps reduce test time across precision applications.
Testwall can supply the used Keysight (Agilent) 6625A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 6625A.
