Keysight (Agilent) 81600B
| Attribute | Value |
|---|---|
| Tunable Wavelength Range | 1450 nm to 1650 nm |
| Output Power | Up to +13 dBm (20 mW) |
| Wavelength Accuracy | ±1 pm |
| Linewidth | <100 kHz |
| Side Mode Suppression Ratio (SMSR) | >60 dB |
| Wavelength Repeatability | ±0.5 pm |
| Output Interface | FC/APC, SC/APC, or LC/APC optical connector |
| Modulation Bandwidth | DC to 1 GHz (internal modulation) |
| Polarization Extinction Ratio | >25 dB |
| Form Factor | Modular mainframe plug-in module (compatible with Keysight 8164B/8166B mainframes) |
Keysight Technologies 81600B Options:
- 81600B - 200 - All-band Tunable Laser Source, 1440 nm to 1640 nm, low SSE
- 81600B - 160 - Tunable Laser Source, 1495 nm to 1640 nm, low SSE
- 81600B - 150 - Tunable Laser Source, 1450 nm to 1590 nm, low SSE
- 81600B - 140 - Tunable Laser Source, 1370 nm to 1495 nm, low SSE
- 81600B - 130 - Tunable Laser Source, 1260 nm to 1375 nm, low SSE
- 81600B - 142 - Tunable Laser Source, 1370 nm to 1495 nm, high power
- 81600B - 132 - Tunable Laser Source, 1260 nm to 1375 nm, high power
- 81600B - 071 - PMF, straight contact output connector
- 81600B - 072 - PMF, angled contact output connector
- 81600B - 003 - Built-in optical attenuator, 60 dB attenuation (for Option 142)
| Model | 81600B |
|---|
The Keysight (Agilent) 81600B Tunable Laser Source is engineered for high precision with a variable sweep speed up to 80 nm/s and an extensive tuning range of 1260 nm to 1640 nm. Integrated features include a 60 dB attenuator, high accuracy wavemeter (±3.6 pm), and a low spontaneous emission signal output (SSE >70 dB/nm), allowing top-tier performance in optical testing.
Ideal for WDM testing, amplifier and receiver characterization, and broadband component assessment, this source reduces test complexity with coherence control and external wavelength locking capabilities.
Testwall can supply the used Keysight (Agilent) 81600B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 81600B.
