Keysight (Agilent)
Keysight (Agilent) 81680A
1460 nm to 1580 nm Wavelength Range
±0.001 nm (±1 pm) Wavelength Accuracy
Up to 100 nm/s continuous sweep Tuning Speed
-10 dBm to +7 dBm Output Power Range
±0.5 dB Power Accuracy
| Attribute | Value |
|---|---|
| Wavelength Range | 1460 nm to 1580 nm |
| Wavelength Accuracy | ±0.001 nm (±1 pm) |
| Tuning Speed | Up to 100 nm/s continuous sweep |
| Output Power Range | -10 dBm to +7 dBm |
| Power Accuracy | ±0.5 dB |
| Linewidth | <100 kHz |
| Side Mode Suppression Ratio (SMSR) | >50 dB |
| Output Interface | FC/APC optical connector |
| Module Interface | Compatible with Keysight 8164A/8166A mainframes |
| Wavelength Resolution | 0.0001 nm (0.1 pm) |
| Model | 81680A |
|---|
The Keysight (Agilent) 81680A is a precision tunable laser source designed for testing critical DWDM passive components within the C-Band, offering a wavelength range of 1460nm to 1580nm and max output power of 6dBm.
With ±0.01nm wavelength accuracy and ±0.5pm repeatability, it ensures precise, stable testing for telecom and photonic applications.
Testwall can supply the used Keysight (Agilent) 81680A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 81680A.
