Keysight (Agilent)
Keysight (Agilent) DSO6054L
4 Channel 4GSa/s 500MHz Digital Oscilloscope
500 MHz Bandwidth
4 Number of Channels
4 GSa/s Sample Rate
4 Mpts (standard), 8 Mpts (optional) Memory Depth
8.5-inch WVGA color display Display
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Number of Channels | 4 |
| Sample Rate | 4 GSa/s |
| Memory Depth | 4 Mpts (standard), 8 Mpts (optional) |
| Display | 8.5-inch WVGA color display |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Trigger Types | Edge, Glitch, Pattern, CAN, LIN, I2C, SPI, USB, and more |
| Connectivity | USB, LAN (LXI), GPIB (optional) |
| Model | DSO6054L |
|---|
The Keysight (Agilent) DSO6054L is a compact, high-performance oscilloscope featuring 500 MHz bandwidth, 4 analog channels, and a 4 GSa/s sampling rate. Its 8 Mpts memory depth enables deep signal capture and analysis, while its 1U-high design saves rack space.
This unit is LXI compliant with built-in web browser control for seamless integration into automated test setups. USB, LAN, and GPIB interfaces provide versatile connectivity.
Testwall can supply the used Keysight (Agilent) DSO6054L, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSO6054L.
