Keysight (Agilent) DSOX2004A
| Attribute | Value |
|---|---|
| Number of Channels | 4 Analog Channels |
| Bandwidth | 70 MHz |
| Sample Rate | 2 GSa/s |
| Memory Depth | 1 Mpts (standard) |
| Display | 7-inch WVGA (800 x 480) color display |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Waveform Update Rate | Up to 50,000 waveforms per second |
| Connectivity | USB Host, USB Device, LAN (LXI Core 2011) |
Keysight (Agilent) DSOX2004A Options:
- DSOX2004A - DSOX2MEMUP - Upgrade to 1 Mpts per channel (1 Megapoint memory upgrade)
- DSOX2004A - DSOX2EMBD - Embedded serial triggering and analysis (I²C, SPI)
- DSOX2004A - DSOX2COMP - Computer serial triggering and analysis (RS232/422/485/UART)
- DSOX2004A - DSOX2AUTO - Automotive serial triggering and analysis (CAN, LIN)
- DSOX2004A - DSOX2WAVEGEN - WaveGen (built-in 20 MHz function generator)
- DSOX2004A - DSOXDVM - Integrated digital voltmeter
- DSOX2004A - DSOXEDK - Educator's kit
- DSOX2004A - DSOX2MASK - Mask testing
- DSOX2004A - DSOX2SGM - Segmented memory
- DSOX2004A - DSOX2MSO - Upgrade to 8 digital timing channels (MSO)
- DSOX2004A - DSOX2BW14 - Bandwidth upgrade 70 MHz to 100 MHz, 4 ch, License only
- DSOX2004A - DSOX2BW24 - Bandwidth upgrade 100 MHz to 200 MHz, 4 ch, License only
- DSOX2004A - DSOXLAN - LAN/VGA connection module
- DSOX2004A - DSOXGPIB - GPIB connection module
| Model | DSOX2004A |
|---|
The Keysight (Agilent) DSOX2004A Oscilloscope offers 70 MHz bandwidth across 4 analog channels with up to 1 Mpts memory depth, leveraging MegaZoom IV technology for a 200,000 wfms/s update rate. Its 8.5-inch WVGA display and built-in FFT, 23 measurements, and optional WaveGen generator enhance signal analysis with precision.
With full upgradability including logic analysis, function generation, and serial decoding, the DSOX2004A suits educational setups and advanced testing alike.
Testwall can supply the used Keysight (Agilent) DSOX2004A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSOX2004A.
