Keysight (Agilent) DSOX3012A
| Attribute | Value |
|---|---|
| Number of Channels | 2 Analog Channels |
| Bandwidth | 100 MHz |
| Sample Rate | 2 GSa/s |
| Memory Depth | 1 Mpts Standard (2 Mpts with Memory Upgrade) |
| Display | 8.5-inch WVGA (800 x 480) Color Display |
| Waveform Update Rate | 1,000,000 waveforms per second |
| Vertical Resolution | 8-bit (11-bit with High Resolution Mode) |
| Timebase Range | 2 ns/div to 50 s/div |
| Trigger Types | Edge, Pulse Width, Pattern, OR, Rise/Fall Time, Nth Edge Burst, Runt, Setup & Hold, Video, USB, I2C, SPI, UART/RS232 |
| Connectivity & Interfaces | USB Host, USB Device, LAN (LXI Core), GPIB (Optional) |
| Model | DSOX3012A |
|---|
The Keysight (Agilent) DSOX3012A is a 100 MHz, 2-channel digital oscilloscope with a 4 GSa/s sampling rate, 8.5” WVGA display, and MegaZoom IV memory technology. It offers segmented memory, real-time 12-bit resolution, and an update rate exceeding 1 million waveforms/sec. This fully upgradable model includes a 20 MHz waveform generator, DVM, logic analyzer, and protocol analyzer.
Ideal for engineers needing high-speed signal analysis, the DSOX3012A supports advanced triggering, high memory depth, and 16 digital channels, ensuring efficient debugging and validation.
Testwall can supply the used Keysight (Agilent) DSOX3012A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSOX3012A.
