Keysight (Agilent)
Keysight (Agilent) E1658A
VXI Module Form Factor
C-Size VXI Module Size
8x16 Single-Ended / 4x16 Differential Multiplexer Matrix Switch Function
128 two-wire channels (single-ended) / 64 four-wire channels (differential) Number of Channels
Reed Relay Switch Type
| Attribute | Value |
|---|---|
| Form Factor | VXI Module |
| Module Size | C-Size VXI |
| Function | 8x16 Single-Ended / 4x16 Differential Multiplexer Matrix Switch |
| Number of Channels | 128 two-wire channels (single-ended) / 64 four-wire channels (differential) |
| Switch Type | Reed Relay |
| Maximum Voltage | 300 V DC / 250 V AC RMS |
| Maximum Current | 1 A per channel |
| Maximum Power | 50 W per channel |
| Contact Resistance | Less than 1 Ohm initial |
| Interface/Bus | VXI (VMEbus eXtensions for Instrumentation), Message-Based |
| Model | E1658A |
|---|
The Keysight (Agilent) E1658A is a 34-channel state and timing module engineered for high-speed logic analysis. It features state analysis up to 100 MHz and timing analysis with 4 ns resolution, ensuring accurate digital system debugging.
With 34 channels and seamless compatibility with Keysight logic systems, it is ideal for analyzing complex digital circuits.
Testwall can supply the used Keysight (Agilent) E1658A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E1658A.
