Keysight (Agilent) E4868B
| Attribute | Value |
|---|---|
| Product Family | High-Power Amplifier |
| Frequency Range | 800 MHz to 1000 MHz |
| Output Power | Up to 68 dBm (6.3 W) saturated output power |
| Gain | Minimum 40 dB small-signal gain |
| Input Connector | Type-N Female |
| Output Connector | Type-N Female |
| Power Supply Requirement | 100–240 VAC, 50/60 Hz |
| Cooling Method | Forced Air Cooling (Internal Fan) |
| Operating Temperature | 0°C to 55°C |
| Typical Application | EMC/EMI Testing, Immunity Testing, Wireless Device Testing |
| Model | E4868B |
|---|
The Keysight (Agilent) E4868B is a high-speed 16-channel multiplexer designed to aggregate ParBERT outputs into a single 43/45 Gb/s stream. Supporting sixteen 3.35 Gb/s or four 10.8 Gb/s channels, it is ideal for demanding tests like OC-768, 100 GbE pre-silicon, and DSP stress tests for advanced coherent optics. With SMA-to-1.85 mm cables included and sub-2 ps input skew alignment, it ensures exceptional signal integrity and precision.
Utilizing built-in eye-shaping equalizers, users can emulate transmitter de-emphasis or ISI. The E4868B integrates seamlessly with ParBERT software for pattern control, triggering, and BER analysis.
Testwall can supply the used Keysight (Agilent) E4868B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E4868B.
