Keysight (Agilent)
Keysight (Agilent) E5071A
300 kHz to 8.5 GHz Network Analyzer
300 kHz to 8.5 GHz Frequency Range
2 or 4 ports Number of Ports
Up to 120 dB Dynamic Range
-55 dBm to +10 dBm Output Power Range
S-parameters, impedance, admittance, group delay, phase Measurement Parameters
| Attribute | Value |
|---|---|
| Frequency Range | 300 kHz to 8.5 GHz |
| Number of Ports | 2 or 4 ports |
| Dynamic Range | Up to 120 dB |
| Output Power Range | -55 dBm to +10 dBm |
| Measurement Parameters | S-parameters, impedance, admittance, group delay, phase |
| IF Bandwidth | 10 Hz to 30 kHz |
| Trace Noise (RMS) | 0.004 dB rms at 10 Hz IF bandwidth |
| Display | 10.4-inch color LCD touchscreen |
| Connector Type | N-type 50 Ohm test ports |
| Interface/Connectivity | GPIB, USB, LAN (100Base-T Ethernet) |
Keysight Technologies E5071A Options:
- E5071A - 213 - 2-port S-parameter test set
- E5071A - 214 - 2-port S-parameter test set with extended power range (-50 dBm to 0 dBm)
- E5071A - 313 - 3-port S-parameter test set
- E5071A - 314 - 3-port S-parameter test set with extended power range (-50 dBm to 0 dBm)
- E5071A - 413 - 4-port S-parameter test set
- E5071A - 414 - 4-port S-parameter test set with extended power range (-50 dBm to 0 dBm)
- E5071A - 016 - Touch screen interface
- E5071A - 1E5 - High stability frequency reference (±0.05 ppm, 23°C ± 5°C)
| Model | E5071A |
|---|
The Keysight (Agilent) E5071A ENA Series Network Analyzer supports 2-, 3-, or 4-port configurations with comprehensive mixed-mode S-parameter analysis, fixture de-embedding, and TRL/LRL calibration from 300 kHz to 8.5 GHz.
With 125 dB dynamic range, 9.6 µs/point sweep speed, and 0.001 dB rms trace noise, it’s ideal for high-precision testing of multiport and balanced devices with full port correction.
Testwall can supply the used Keysight (Agilent) E5071A, fully tested.
With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality.
Please contact us directly if you need calibration or repair of the Keysight (Agilent) E5071A..
