Keysight (Agilent)
Keysight (Agilent) E6393B
869 MHz to 894 MHz Frequency Range
AMPS / CDMA (IS-95) Standard Supported
GPIB (IEEE-488) Interface Type
-110 dBm to +10 dBm Output Power Range
30 kHz (AMPS), 1.25 MHz (CDMA) Channel Bandwidth
| Attribute | Value |
|---|---|
| Frequency Range | 869 MHz to 894 MHz |
| Standard Supported | AMPS / CDMA (IS-95) |
| Interface Type | GPIB (IEEE-488) |
| Output Power Range | -110 dBm to +10 dBm |
| Channel Bandwidth | 30 kHz (AMPS), 1.25 MHz (CDMA) |
| Operating Temperature | 0°C to 55°C |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Form Factor | Benchtop |
| Display | Built-in LCD Display |
| Dimensions (W x H x D) | 426 mm x 177 mm x 497 mm |
| Model | E6393B |
|---|
The Keysight (Agilent) E6393B is a high-performance test set developed for cdma2000 and AMPS mobile station analysis, providing precise tools for diagnostics and screening. It enhances service efficiency and cuts down maintenance costs significantly.
This unit is ideal for mobile network providers seeking reliable testing of mobile stations, with advanced capabilities that streamline operations and lower diagnostic time.
Testwall can supply the used Keysight (Agilent) E6393B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E6393B.
