Keysight (Agilent) J2309A
| Attribute | Value |
|---|---|
| Product Family | InfiniiMax III Series Probe Amplifier |
| Bandwidth | 13 GHz |
| Compatible Oscilloscopes | Infiniium Series Oscilloscopes (90000 X-Series, V-Series, Z-Series) |
| Probe Head Compatibility | Compatible with InfiniiMax III probe heads (browser, solder-in, and ZIF tip heads) |
| Input Voltage Range | ±8 V (differential), ±4 V (single-ended) |
| Dynamic Range | ±800 mV (differential input) |
| Power Consumption | Powered via oscilloscope probe interface connector |
| Connector Interface | AutoProbe Interface |
| Operating Temperature | 0°C to 55°C |
| Differential/Single-Ended | Supports both differential and single-ended measurements |
Keysight (Agilent) J2309A Options:
- J2309A - HP J2306A - Ethernet Interface
- J2309A - HP J2309A - Ethernet and Token Ring Interface
- J2309A - HP J2295A - PC Card Undercradle (empty)
- J2309A - HP J2170A - Ethernet/Token Ring Interface Module
- J2309A - HP J2171A - Ethernet Interface Module
- J2309A - HP J2172A - Token Ring Interface Module
- J2309A - HP J2173B - FDDI Single Attach Interface Module
- J2309A - HP J2173C - FDDI Dual Attach with TPPMD Interface Module
- J2309A - HP J2208B - 64 Kb/s WAN Interface Module
- J2309A - HP J2272A - T1 Interface Module
- J2309A - HP J2273A - E1 Interface Module
- J2309A - HP J2260A - Ethernet PC Card
- J2309A - HP J2261A - Token Ring PC Card
- J2309A - HP J2308A - Ethernet and Token Ring PC Cards
- J2309A - HP J2188A - Soft Carrying Case for Network Advisor
- J2309A - HP J2209A - Soft Carrying Case for Interface Module
- J2309A - HP J2527A - TIMS Interface
| Model | J2309A |
|---|
The Keysight (Agilent) J2309A provides protocol decodes for a wide array of major protocol stacks including TCP/IP, Novell, 3COM, DECnet, SNA, Banyan, Sun SNS, IBM PC LAN, ISO, AppleTalk, and Microsoft LAN Manager. It features intelligent commentators and vital signs that correlate network and protocol statistics with significant network events for enhanced diagnostics. Its superior hardware filters, RISC processor, and extensive capture buffer ensure full-rate data capture and support simultaneous, multi-measurement capabilities.
This unit is ideal for complex network analysis and performance monitoring in enterprise environments. It supports advanced measurements and protocol evaluation without data loss.
Testwall can supply the used Keysight (Agilent) J2309A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) J2309A.
