Keysight (Agilent)
Keysight (Agilent) N5230A-525
300 kHz to 50 GHz, Network Analyzer, 2.4 mm (m)
300 kHz to 13.5 GHz Frequency Range
4 Number of Ports
Up to 122 dB Dynamic Range
-85 dBm to +20 dBm Output Power Range
Up to 42 µs per point Measurement Speed
| Attribute | Value |
|---|---|
| Frequency Range | 300 kHz to 13.5 GHz |
| Number of Ports | 4 |
| Dynamic Range | Up to 122 dB |
| Output Power Range | -85 dBm to +20 dBm |
| Measurement Speed | Up to 42 µs per point |
| Connector Type | 3.5 mm (f) |
| Trace Noise | 0.004 dB RMS |
| IF Bandwidth | 1 Hz to 40 kHz |
| System Impedance | 50 Ohm |
| Display | 10.4-inch XGA color LCD touchscreen |
Keysight Technologies N5230A-525 Options:
- N5230A-525 - 020 - Standard test set and standard power range, 300 kHz to 6 GHz
- N5230A-525 - 025 - Configurable test set and extended power range, 300 kHz to 6 GHz
- N5230A-525 - 120 - Standard test set and standard power range, 300 kHz to 13.5 GHz
- N5230A-525 - 125 - Configurable test set and extended power range, 300 kHz to 13.5 GHz
- N5230A-525 - 220 - Standard test set and standard power range, 10 MHz to 20 GHz
- N5230A-525 - 225 - Configurable test set and extended power range, 10 MHz to 20 GHz
- N5230A-525 - 420 - Standard test set and standard power range, 10 MHz to 40 GHz
- N5230A-525 - 425 - Configurable test set and extended power range, 10 MHz to 40 GHz
- N5230A-525 - 520 - Standard test set and standard power range, 10 MHz to 50 GHz
- N5230A-525 - 525 - Configurable test set and extended power range, 10 MHz to 50 GHz
- N5230A-525 - 080 - Fast CW mode
- N5230A-525 - H08 - Rack mount kit
- N5230A-525 - H11 - Rack mount kit with handles
| Model | N5230A-525 |
|---|
The Keysight (Agilent) N5230A-525 4-port model offers dynamic power scaling and a wide frequency reach up to 50 GHz, ideal for complex RF environments. With integrated bias-tee and advanced attenuator features, it supports pulse-ready testing with superior control.
This unit is perfect for high-frequency measurements and modular configurations, enhancing precision in RF analysis tasks across demanding applications.
Testwall can supply the used Keysight (Agilent) N5230A-525, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N5230A-525.
