Keysight (Agilent) N6030A
| Attribute | Value |
|---|---|
| Channels | 2 channels |
| Vertical Resolution | 15 bit |
| Harmonic Distortion | ≤ -65 dBc DC to 500 MHz |
| Interfaces | CompactPCI, 4 slots |
| Dimensions | 81 × 130 × 216 mm |
| Frequency Range | 500 MHz bandwidth per channel (1 GHz I/Q) |
| Sample Rate | 1.25 GSa/s (external clock 100 MSa/s to 1.25 GSa/s) |
| Amplitude | 0.5 Vpp passive, 1 Vpp active, 1 Vpp direct DAC into 50 Ω |
| Arbitrary Memory | 8 MSa per channel |
| Weight | 1.14 kg |
Keysight Technologies N6030A Options:
- N6030A - 016 - Waveform memory expansion to 16 MS memory per channel
- N6030A - 300 - Enabling software for 16-bit dynamic sequencing (requires U.S. export license)
- N6030A - 330 - Direct digital synthesis software (requires U.S. export license)
- N6030A - 500 - PXI 18-slot chassis
- N6030A - 501 - PXI embedded controller, P4
- N6030A - 502 - PXI MXI-4 kit (includes PC and chassis PCI cards)
- N6030A - 503 - Shielded PXI chassis filler panel kit
- N6030A - 504 - 17-inch flat panel monitor
- N6030A - 505 - PS2 keyboard and mouse
- N6030A - 506 - Rack mount kit for PXI chassis
The Keysight (Agilent) N6030A Arbitrary Waveform Generator delivers 500 MHz modulation bandwidth per channel, 1.25 GS/s sampling rate, and 15-bit vertical resolution. It enables creation of high-fidelity, wideband signals essential for advanced RADAR, EW, and satellite system testing. With dual outputs and support for multiple module synchronization, it facilitates realistic signal simulations.
Utilizing MATLAB® integration and options like dynamic sequencing and direct digital synthesis, users can efficiently craft and deploy complex modulation scenarios across differential or single-ended outputs.
Testwall can supply the used Keysight (Agilent) N6030A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N6030A.
Options and configurations
- Arbitrary Memory: 8 MSa per channel (16 MSa with Opt. 016)
