Keysight (Agilent)
Keysight (Agilent) N6744B
DC Power Module, 35V, 3A, 100W
0 to 20 V Output Voltage
0 to 3.5 A Output Current
70 W Output Power
0.05% + 10 mV Programming Accuracy (Voltage)
0.1% + 3.5 mA Programming Accuracy (Current)
| Attribute | Value |
|---|---|
| Output Voltage | 0 to 20 V |
| Output Current | 0 to 3.5 A |
| Output Power | 70 W |
| Programming Accuracy (Voltage) | 0.05% + 10 mV |
| Programming Accuracy (Current) | 0.1% + 3.5 mA |
| Readback Accuracy (Voltage) | 0.05% + 10 mV |
| Readback Accuracy (Current) | 0.1% + 3.5 mA |
| Number of Output Channels | 1 (single output module) |
| Compatible Mainframe | Keysight N6700 Series Modular Power System |
| Output Noise (Voltage, 20 Hz to 20 MHz) | 3 mV rms / 15 mV peak-to-peak |
Keysight (Agilent) N6744B Options:
- N6744B - 054 - High-speed Test Extensions (output list and digitized measurement capability)
- N6744B - 760 - Output disconnect/polarity reversal relays
- N6744B - 761 - Output disconnect relays
| Model | N6744B |
|---|
The Keysight (Agilent) N6744B is a 105 W basic DC power module offering 35 V and 3 A output, with 0.1% voltage and 0.15% current programming accuracy, plus ripple as low as 5 mV rms and 2 mA rms.
Compatible with N6700 and N6705 systems, it features GPIB, LAN, USB, and LXI Class C compliance, ideal for DUT power or fixture control in ATE setups.
Testwall can supply the used Keysight (Agilent) N6744B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N6744B.
