Kikusui PCR1000M
| Attribute | Value |
|---|---|
| Output Capacity | 1000 VA |
| Output Voltage Range | 0 – 150 V / 0 – 300 V (switchable) |
| Output Frequency Range | 45 – 500 Hz |
| Output Current (Max) | 6.7 A (150 V range) / 3.3 A (300 V range) |
| Voltage Setting Resolution | 0.1 V |
| Frequency Setting Resolution | 0.01 Hz |
| Total Harmonic Distortion (THD) | ≤ 0.5% (resistive load, 45–200 Hz) |
| Input Voltage | Single-phase 200 – 240 VAC, 50/60 Hz |
| Interfaces | RS-232C standard; GP-IB / USB optional |
| Dimensions (W × H × D) | 215 mm × 132 mm × 450 mm |
Kikusui PCR1000M 1000VA Voltage/Frequency Converter Options:
- PCR1000M - EX04-PCR-M - Analogue Interface Board
- PCR1000M - IB21 - Gpib Option
- PCR1000M - UB21 - Usb Option
| Model | PCR1000M |
|---|
The Kikusui PCR1000M Voltage/Frequency Converter delivers 1V–270V AC and 1.4V–380V DC outputs with a 1000VA/1000W capacity, supporting peak currents three times its rated RMS current. Compact and lightweight, it employs PWM inverter technology to ensure high-efficiency (around 70%) performance. Features include integrated measurement, memory, protection, and optional analog interfaces for expanded functionality, including booster use with arbitrary signal generators.
Ideal for varied lab or field applications, this unit is multifunctional, compact, and supports versatile output configurations including AC and DC, memory recall, and communication interfaces.
Testwall can supply the used Kikusui PCR1000M, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Kikusui PCR1000M.
