Kikusui PLZ164WL
| Attribute | Value |
|---|---|
| Maximum Power | 165 W |
| Maximum Voltage | 150 V |
| Maximum Current | 30 A |
| Minimum Operating Voltage | 1.5 V |
| Operating Modes | CC, CV, CR, CP |
| Input Interface | USB, RS-232C, GP-IB (optional) |
| Transient Response Speed | Fast / Slow switchable |
| Dynamic Mode Frequency | 10 kHz maximum |
| Power Supply Requirement | 100–240 V AC, 50/60 Hz |
| Dimensions (W x H x D) | 213 mm x 88 mm x 350 mm |
Kikusui PLZ164WL Options:
- PLZ164WL - TL01-PLZ - Low inductance cable (50cm)
- PLZ164WL - TL02-PLZ - Low inductance cable (1m)
- PLZ164WL - TL03-PLZ - Low inductance cable (2m)
- PLZ164WL - OP01-PLZ-4WL - Analog remote control connector kit
- PLZ164WL - KRA150 - Rack mount accessories (millimeter size)
- PLZ164WL - KRA3 - Rack mount accessories (inch size)
- PLZ164WL - Wavy for PLZ-4W - Application Software (current waveform simulation and data logging)
| Model | PLZ164WL |
|---|
KIKUSUI PLZ164WL DC Electronic Load
While the Kikusui PLZ164WL succeeds to the superior operability of our conventional model of the PLZ-4W series, the PLZ164WL realizes the high speed rise and fall time (slew rate of 50A/ µs.) in the range of low voltage with large current. The PLZ-4WL offers six operation modes, and equips with various features such as sequence operation, switching operation, soft-start function, and time and voltage measurement. Each operation mode of the CC, CR, and CP has 3 ranges (H, M, L). The "L "range employs the scale of 1/100 which covers the range from the small to the large scale of the current.
The Kikusui PLZ164WL applies not only for the conventional load test of the CPU power supply, but also it can be applied to even faster cur response test. In addition, the PLZ-4WL is a space-saving design (about 50% less volume of the conventional model) that can save the facility space of the testing site, and it can be applied for the single cell testing of the large scale rechargeable battery. The sequence mode can be set in 2 operation modes (Normal and Fast mode). The Fast mode can be set for the minimum step time of 25 µs, and it can be synchronized with the external device by using the trigger input/output feature.
Specifications for the KIKUSUI PLZ164WL DC Electronic Load Include:
| Voltage Range | 0.3 to 30V |
| Cur Range | 50A |
| Total Power | 165W |
| Min Start Voltage | 50mV |
