Leader
Leader LG-1311
10 MHz Function Generator.
100 kHz to 150 MHz Frequency Range
0.1 mV to 100 mV (into 50Ω) Output Level
AM and FM Modulation Type
0 to 50% AM Modulation Depth
0 to 75 kHz FM Deviation
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 150 MHz |
| Output Level | 0.1 mV to 100 mV (into 50Ω) |
| Modulation Type | AM and FM |
| AM Modulation Depth | 0 to 50% |
| FM Deviation | 0 to 75 kHz |
| Output Impedance | 50Ω |
| Frequency Accuracy | ±1% of dial setting |
| Modulation Frequency | 400 Hz and 1 kHz internal |
| Power Supply | AC 100/120/220/240V, 50/60 Hz |
| Dimensions | 260 mm (W) x 130 mm (H) x 280 mm (D) |
Leader LG-1311 Options:
- LG-1311 - LT-2049 - 50 Ω Terminator (Optional Accessory)
| Model | LG-1311 |
|---|
The Leader LG-1311 is a 10 MHz Function Generator.
