Marconi IFR Aeroflex 2975
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 1 GHz |
| RF Output Level | -137 dBm to +13 dBm |
| Frequency Resolution | 1 Hz |
| Modulation Types | AM, FM, Phase Modulation, Pulse Modulation |
| FM Deviation Range | Up to 150 kHz |
| AM Depth Range | 0% to 99.9% |
| RF Connector Type | N-Type Female |
| Power Supply | 90 to 265 VAC, 47 to 440 Hz |
| Operating Temperature Range | 0°C to 55°C |
| Interface | GPIB (IEEE-488), RS-232 |
Marconi IFR Aeroflex 2975 Options:
- 2975 - OPT3 - SmartNet™/SmartZone™ VHF/UHF and 800 MHz
- 2975 - OPT4 - P25 Trunking 800 MHz
- 2975 - OPT6 - Control Channel Logger
- 2975 - OPT8 - SmartNet™/SmartZone™ 900 MHz (Requires 2975OPT3)
- 2975 - OPT9 - Autotest 1
- 2975 - OPT10 - AES (Export Restricted)
- 2975 - OPT12 - KVL Keyloader
- 2975 - OPT14 - P25 Trunking VHF/UHF/700 MHz
- 2975 - OPT15 - Audio Analyzer
- 2975 - OPT16 - Analog Simulcast Align (Requires 2975OPT15)
- 2975 - OPT17 - RXBER
- 2975 - OPT18 - LTR® Trunking
- 2975 - OPT19 - PassPort® (Requires Version 1.9.x or later Firmware)
- 2975 - OPT20 - KVL ASN Mode (Requires 2975OPT12)
- 2975 - OPT21 - P25 Secondary Control Channel Broadcast Message (Requires 2975OPT4)
- 2975 - OPT22 - P25 Explicit Mode Operation (Requires 2975OPT14)
- 2975 - OPT23 - P25 Explicit Unit to Unit and PSTN Emulation (Requires 2975OPT22)
- 2975 - OPT24 - P25 Explicit Adjacent Status Broadcast Channel Message (Requires 2975OPT22)
- 2975 - OPT29 - CQPSK Generate/Receive and Analysis
| Model | 2975 |
|---|
The Marconi-IFR-Aeroflex 2975 is a high-performance radio communications test set designed for modern analog and digital systems. It offers wideband frequency coverage, precise analysis, and advanced modulation testing. Equipped with integrated RF, audio, and modulation tools, it ensures comprehensive testing capabilities in one compact system.
Its rugged yet portable design makes it suitable for both laboratory and field applications, providing engineers with flexibility and efficiency. The user-friendly interface supports reliable and accurate measurements across diverse test environments.
Testwall can supply the used Marconi-IFR-Aeroflex 2975, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Marconi-IFR-Aeroflex 2975.
