Marconi IFR Aeroflex 500
| Attribute | Value |
|---|---|
| Frequency Range | 10 Hz to 500 kHz |
| Output Voltage | Up to 10 V RMS |
| Waveform Types | Sine, Square, Triangle |
| Frequency Accuracy | ±0.1% |
| Output Impedance | 600 Ohms |
| Distortion (THD) | Less than 0.5% (sine wave) |
| Power Supply | 115/230 V AC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
| Display | Analog meter with frequency and amplitude indication |
| Dimensions | Approximately 130 x 280 x 230 mm |
Marconi IFR Aeroflex 500 Options:
- 500 - A-3 - Generate Amplifier (Optional): 30 ±2 dB typical gain, 100 kHz to 1000 MHz
- 500 - Optional TCXO - Master Oscillator Optional TCXO: 0.2 PPM stability (0-50°C), 3 PPM first year aging
- 500 - Optional Oven - Master Oscillator Optional Oven (Prohibits internal battery installation): 0.05 PPM accuracy (0-50°C), 1 PPM per year aging
- 500 - High Resolution Option - Frequency Error Meter High Resolution Option: ±300 Hz, ±100 Hz, ±30 Hz full scale ranges
- 500 - Variable Tone Generator - Variable Tone Generator option for FM/AM-500 (standard on FM/AM-500A)
- 500 - Internal Battery - Optional Internal Battery: approximately 2 hours operation
- 500 - 5106-4900-125 - Microphone Jack: Special, IFR P/N 5106-4900-125
| Model | 500 |
|---|
The Marconi-IFR-Aeroflex 500 Signal Generator delivers clean and stable RF signals across a broad frequency range, making it suitable for demanding test and measurement applications. Supporting AM, FM, and pulse modulation, it ensures precise frequency synthesis and dependable low-noise output. Its rugged design and user-friendly interface make it adaptable for both laboratory and industrial environments.
Engineered for flexibility, the Aeroflex 500 is ideal for communications development, manufacturing, and servicing tasks. Its low distortion and accurate RF performance ensure consistent results in both analog and digital testing scenarios.
Testwall can supply the used Marconi-IFR-Aeroflex 500 Signal Generator, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Marconi-IFR-Aeroflex 500 Signal Generator.
