Megger MIT515
| Attribute | Value |
|---|---|
| Test Voltage Range | 100 V, 250 V, 500 V, 1000 V, 2500 V, 5000 V DC |
| Maximum Insulation Resistance Measurement | 15 TΩ |
| Insulation Resistance Measurement Range | 10 kΩ to 15 TΩ |
| Voltage Measurement (AC/DC) | Up to 600 V AC/DC |
| Display Type | Dual digital and analog LCD display |
| Test Functions | Insulation Resistance (IR), Dielectric Absorption Ratio (DAR), Polarization Index (PI), Dielectric Discharge (DD), Step Voltage (SV) |
| Power Source | 6 x AA alkaline batteries or optional AC adapter |
| Battery Life | Approximately 500 tests at 5000 V on alkaline batteries |
| IP Rating / Environmental Protection | IP54 (dust and splash protected) |
| Operating Temperature Range | -20°C to +55°C (-4°F to +131°F) |
| Model | MIT515 |
|---|
The Megger MIT515 is a compact 5 kV insulation resistance tester designed for high voltage electrical equipment testing. With CAT IV 600 V safety rating, it supports IR, DAR, PI, and DD tests while offering selectable test voltages from 250 V to 5000 V. It measures insulation resistance up to 10 TΩ and features a large backlit display, intuitive dual rotary switches, and a built-in Quick Start Guide for effortless operation.
Applications include cables, transformers, motors, generators, circuit breakers, and bushings. The unit enables spot tests, 1-minute IR testing, and 10-minute PI tests, ensuring accurate, temperature-independent results. It also operates from mains power if the battery is depleted, with a rapid-charge Li-ion battery for extended use.
Testwall can supply the used Megger MIT515 Insulation Tester, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Megger MIT515 Insulation Tester.
