National Instruments PXIE-5122
| Attribute | Value |
|---|---|
| Number of Channels | 2 analog input channels |
| Resolution | 14-bit |
| Maximum Sample Rate | 100 MS/s |
| Input Impedance | 50 Ω or 1 MΩ (software selectable) |
| Input Voltage Range | ±0.5 V to ±5 V (with 50 Ω termination); ±0.5 V to ±25 V (with 1 MΩ termination) |
| Bandwidth | 50 MHz |
| Onboard Memory | 256 MB per channel |
| Bus Interface | PXI Express (PXIe) |
| Coupling | AC or DC (software selectable) |
| Operating Temperature | 0 °C to 55 °C |
| Model | PXIE-5122 |
|---|
The National Instruments PXIe-5122 100MS/s 14-bit Oscilloscope offers high-resolution digitization with a sampling rate of 100MS/s and 14-bit vertical resolution, delivering precise waveform capture for advanced applications. It features two simultaneous channels and deep onboard memory, ensuring accurate acquisition across a wide range of frequencies with minimal distortion.
Ideal for demanding signal analysis, this PXIe module supports high-speed data transfer and integrates seamlessly into modular test systems for laboratory and production environments.
Testwall can supply the used National Instruments PXIe-5122 100MS/s 14-bit Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the National Instruments PXIe-5122 100MS/s 14-bit Oscilloscope.
