NH Research 4760-36
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 – 36 V |
| Output Current Range | 0 – 60 A |
| Output Power | 2160 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47 – 63 Hz |
| Regulation (Voltage) | 0.05% + 5 mV |
| Regulation (Current) | 0.1% + 10 mA |
| Ripple and Noise (Voltage) | 5 mV RMS / 30 mV Peak-to-Peak |
| Programming Interface | GPIB (IEEE-488), RS-232 |
| Operating Temperature | 0°C to 50°C |
| Model | 4760-36 |
|---|
The NH Research 4760-36 Electronic Load from the 4760 LXI Series is engineered for demanding high-power and high-voltage applications. It integrates a unique Auto Mode enabling seamless switching between CR, CC, CV, and CP limits without glitches. Equipped with 100-step macro-recording for precise sequence playback, it ensures accurate dynamic performance measurements during UUT testing. Its modular, synchronously controlled, and actively power-balanced design allows parallel operation as a single efficient load.
Ideal for testing power conversion systems, telecom rectifiers, fuel cells, and Vehicle-to-Grid (V2G) applications, the NH Research 4760-36 eliminates the need for additional instruments and simplifies complex multi-mode load recreations with high accuracy.
Testwall can supply the used NH Research 4760-36, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the NH Research 4760-36.
