NH Research 9430
| Attribute | Value |
|---|---|
| Output Power | Up to 18 kW |
| Output Voltage Range | 0 – 600 V DC |
| Output Current Range | 0 – 30 A |
| Input Voltage | 208/480 V AC, Three-Phase |
| Operating Mode | Regenerative AC-DC Power Supply |
| Efficiency | Up to 94% |
| Communication Interfaces | IEEE-488 (GPIB), RS-232, Analog |
| Cooling Method | Forced Air Cooling |
| Form Factor | Rack Mountable |
| Regulatory Compliance | CE Marked, UL Listed |
NH Research 9430 Options:
- 9430 - 4 - 4kW AC Load
- 9430 - 8 - 8kW AC Load
- 9430 - 12 - 12kW AC Load
- 9430 - 24 - 24kW AC Load
- 9430 - 36 - 36kW AC Load
- 9430 - 48 - 48kW AC Load
- 9430 - 72 - 72kW AC Load
- 9430 - 96 - 96kW AC Load
| Model | 9430 |
|---|
The NH Research 9430 4-Quadrant Regenerative AC Load offers advanced capabilities with selectable single, split, or three-phase inputs, handling 10–350VAC and 30–880Hz ranges. Its HIVAR® design supports reactive power up to 2.6× real power, while modes including CC, CR, CP, CS, and CRL allow precise emulation of linear, non-linear, and inductive loads. It delivers power densities from 4kW to 96kW with a high-resolution waveform digitizer and intuitive 9” touch-panel control.
Ideal for testing UPS systems, AC sources, inverters, rectifiers, and protective devices, the NHR 9430 operates in all four quadrants, regenerating over 90% of sink power back to facility mains. This ensures significant energy savings and reduces cooling requirements.
Testwall can supply the used NH Research 9430 4-Quadrant Regenerative AC Load, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the NH Research 9430 4-Quadrant Regenerative AC Load.
