Noyes Fiber Systems M200-K-MM
| Attribute | Value |
|---|---|
| Fiber Type | Multimode |
| Wavelengths | 850 nm / 1300 nm |
| Dynamic Range | Up to 25 dB |
| Light Source Type | LED |
| Measurement Range | 0.1 dB to 60 dB |
| Display Resolution | 0.01 dB |
| Connector Interface | Universal 2.5 mm adapter |
| Power Supply | 9V Battery |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Standards Compliance | TIA/EIA-526-14A, TIA/EIA-526-7 |
| Model | Fiber |
|---|
The Noyes Fiber Systems M200 from AFL is a lightweight handheld OTDR, weighing just 0.9 kg, offering multimode, single-mode, and quad wavelength options. It delivers short 1.5 m event dead zones, dynamic range up to 26 dB, and supports Tier 2 testing, FTTX PON certification, and troubleshooting with precision. The transflective touchscreen ensures usability indoors and outdoors, while the rugged polycarbonate case enhances durability.
With automatic and manual setup, dual-wavelength testing, precision event analysis, and integrated VFL, the M200 is designed for fast fault location, splice verification, and reliable network documentation. Tool-free adapters, USB connectivity, CompactFlash memory, and 6-hour Li-Ion battery life make it efficient and user-friendly.
Testwall can supply the used Noyes Fiber Systems M200, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Noyes Fiber Systems M200.
