Pacific Power 105LMX
| Attribute | Value |
|---|---|
| Output Voltage Range | 0–300 VAC (Single Phase), Continuously Variable |
| Output Frequency Range | 45–500 Hz, Continuously Variable |
| Power Rating | 500 VA |
| Output Waveform | True Sine Wave |
| Input Voltage | 120 VAC, Single Phase |
| Input Frequency | 47–63 Hz |
| Total Harmonic Distortion (THD) | Less than 0.5% at Full Resistive Load |
| Output Current | Up to 4.2 A RMS |
| Voltage Regulation | ±0.1% from No Load to Full Load |
| Control Interface | Front Panel with Digital Display and Manual Controls |
Pacific Power 105LMX Options:
- 105LMX - 110 - AC Input Voltage: 110 VAC, 1-Phase
- 105LMX - 120 - AC Input Voltage: 120 VAC, 1-Phase
- 105LMX - 220 - AC Input Voltage: 220 VAC, 1-Phase
- 105LMX - 230 - AC Input Voltage: 230 VAC, 1-Phase
- 105LMX - 240 - AC Input Voltage: 240 VAC, 1-Phase
- 105LMX - PPSC Test Manager SW License - PPSC Test Manager Software License
- 105LMXT - 1.5:1 - Transformer Option, 1.5:1 Ratio (0-202/404 V, 2.6/1.3 Arms)
- 105LMXT - 2.0:1 - Transformer Option, 2.0:1 Ratio (0-270/540 V, 2/1 Arms)
- 105LMXT - 2.5:1 - Transformer Option, 2.5:1 Ratio (0-338/600 V, 1.6/0.8 Arms)
- 105LMXT - Avionics Test Sequences - Avionics Test Sequences Option
- 105LMXT - IEC Test Sequences - IEC Test Sequences Option
| Model | 105LMX |
|---|
The Pacific Power 105LMX is a high-performance Linear AC Power Source delivering stable output across 15 to 5,000 Hz with quartz-crystal stabilized frequency control. It supports voltages up to 135VL-N in single-phase and 270VL-L in split-phase mode, making it ideal for precision testing applications requiring low distortion and high waveform fidelity.
Offering two-phase output, the 105LMX efficiently converts one-phase input into controlled split-phase power. Its versatile design makes it suitable for frequency conversion, harmonic testing, and advanced transient simulation in both laboratory and industrial environments.
Testwall can supply the used Pacific Power 105LMX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power 105LMX.
