Pacific Power 140LSX
| Attribute | Value |
|---|---|
| Output Power | 140 VA |
| Output Voltage Range | 0–300 VAC |
| Output Frequency Range | 45–500 Hz |
| Number of Output Phases | Single Phase |
| Input Voltage | 120 VAC |
| Input Frequency | 50/60 Hz |
| Waveform | True Sine Wave |
| Total Harmonic Distortion (THD) | Less than 0.5% at full resistive load |
| Voltage Regulation | ±0.1% or better |
| Form Factor | Benchtop |
Pacific Power 140LSX Options:
- 140LSX - T - Transformer Option (Direct/Transformer Coupled Selectable Output, 45 Hz - 1200 Hz, turns ratios 1:1.5, 1:2.0, 1:2.5)
- 140LSX - C - Interharmonics Generator Option
- 140LSX - E - Export Version
- 140LSX - LSXM - Reduced Feature Set Economy Version (Sine wave output only, fixed phase angles, no transient programming, no harmonic measurements, no waveform capture, no programmable output impedance)
| Model | 140LSX |
|---|
The Pacific Power 140LSX Power Source features advanced low-noise, low-distortion analog power conversion technology, delivering superior voltage quality and high peak current capability. It supports frequencies from 15Hz to 1200Hz, including both fixed 400Hz and wild frequency ranges from 360Hz to 800Hz with exceptional harmonic support. Users benefit from extensive control over voltage, current, frequency, phase angles, and transients, making complex TPS handling efficient.
Designed for versatility, the 140LSX offers intuitive operation through a large full-color LCD display with spreadsheet-style data entry. Engineers can easily create voltage, waveform, and frequency transients from the front panel. It excels in AC compliance testing, transformer evaluation, appliance verification, UPS assessment, and more.
Testwall can supply the used Pacific Power 140LSX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power 140LSX.
