Pacific Power 160LMX
| Attribute | Value |
|---|---|
| Output Voltage Range | 0–300 VAC (single phase), programmable |
| Output Frequency Range | 45–500 Hz, programmable |
| Power Rating | 1600 VA / 1.6 kVA |
| Output Current (Max) | Up to 13.3 A RMS (at 120 VAC) |
| Input Voltage | 105–125 VAC, single phase, 50/60 Hz |
| Waveform | True sine wave output |
| Voltage Regulation | ±0.1% of full scale |
| Frequency Resolution | 0.1 Hz |
| Output Phases | Single phase |
| Control Interface | Front panel digital controls with programmable memory settings |
Pacific Power 160LMX Options:
- 160LMX - T=1.5:1 - Optional Step-Up Transformer, 1.5:1 Ratio (160LMXT)
- 160LMX - T=2.0:1 - Optional Step-Up Transformer, 2.0:1 Ratio (160LMXT)
- 160LMX - T=2.5:1 - Optional Step-Up Transformer, 2.5:1 Ratio (160LMXT)
- 160LMX - VIN:208 - AC Input Voltage 208 Vac, 3-Phase Delta
- 160LMX - VIN:220 - AC Input Voltage 220 Vac, 3-Phase Delta
- 160LMX - VIN:240 - AC Input Voltage 240 Vac, 3-Phase Delta
- 160LMX - VIN:380 - AC Input Voltage 380 Vac, 3-Phase Delta
- 160LMX - VIN:416 - AC Input Voltage 416 Vac, 3-Phase Delta
- 160LMX - VIN:480 - AC Input Voltage 480 Vac, 3-Phase Delta (Optional)
- 160LMX - SW - PPSC Test Manager Software License
- 160LMX - SEQ - Avionics or IEC Test Sequences
| Model | 160LMX |
|---|
The Pacific Power 160LMX is the most powerful member of the LMX-Series, delivering low output voltage noise, minimal distortion, and superior waveform fidelity. Operating across 15 to 5,000 Hz with quartz-crystal stabilized frequency, it offers up to 135VL-N single-phase and 270VL-L split-phase, extendable to 600VL-L in the 160LMXT model. Integrated microcontroller functions make it suitable for precise testing and programmable transient simulations.
Engineered for versatile applications, the 160LMX supports harmonic testing, frequency conversion, and stable AC voltage supply. With two-phase output capability, it effectively converts single-phase line voltage into highly controlled split output power.
Testwall can supply the used Pacific Power 160LMX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power 160LMX.
