Pacific Power 308LMX
| Attribute | Value |
|---|---|
| Output Voltage Range | 0–300 VAC |
| Output Frequency Range | 45–5000 Hz |
| Power Rating | 8 kVA |
| Number of Phases | Single Phase / Three Phase Selectable |
| Output Current (Max) | 27 A (Single Phase), 15.6 A (Three Phase) |
| Input Voltage | 208/240 VAC, Single Phase |
| Total Harmonic Distortion (THD) | Less than 0.5% at full linear load |
| Voltage Regulation | ±0.1% or better |
| Frequency Accuracy | ±0.01% or better |
| Control Interface | Front Panel Display with Programmable Memory Settings |
Pacific Power 308LMX Options:
- 308LMX - 110 - AC Input Voltage 110 VAC, 1-Phase
- 308LMX - 120 - AC Input Voltage 120 VAC, 1-Phase
- 308LMX - 220 - AC Input Voltage 220 VAC, 1-Phase
- 308LMX - 230 - AC Input Voltage 230 VAC, 1-Phase
- 308LMX - 240 - AC Input Voltage 240 VAC, 1-Phase
- 308LMX - PPSC - PPSC Test Manager SW License
- 308LMXT - T1.5 - Optional Step-Up Transformer, Ratio 1.5:1
- 308LMXT - T2.0 - Optional Step-Up Transformer, Ratio 2.0:1
- 308LMXT - T2.5 - Optional Step-Up Transformer, Ratio 2.5:1
- 308LMXT - AVIONICS - Avionics or IEC Test Sequences
- 308LMXTE - E - Export Version (for use outside of the USA)
| Model | 308LMX |
|---|
The Pacific Power 308LMX is a three-phase Linear AC Power Source from the LMX-Series, designed for precision applications. It delivers stable AC voltage with quartz-crystal stabilized frequency control, spanning from 15 to 5,000 Hz. The unit provides output voltages up to 135VL-N in single-phase, 270VL-L in split-phase, and 585VL-L in three-phase modes. Equipped with a powerful micro-controller, the 308LMX supports advanced harmonic testing and programmable transient simulation, while maintaining low output noise and distortion.
This versatile AC source is ideal for frequency conversion, split-phase power generation, and complex testing environments. Its high waveform fidelity and flexible control options make it suitable for both manual and automated test setups.
Testwall can supply the used Pacific Power 308LMX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power 308LMX.
