Pacific Power 312LMX
| Attribute | Value |
|---|---|
| Output Voltage Range | 0–300 VAC |
| Output Frequency Range | 45–500 Hz |
| Output Power Rating | 1.5 kVA |
| Number of Output Phases | Single Phase |
| Input Voltage | 105–125 VAC, Single Phase |
| Input Frequency | 47–63 Hz |
| Output Current (Max) | 5 A |
| Total Harmonic Distortion (THD) | Less than 0.5% at full linear load |
| Voltage Regulation | ±0.1% from no load to full load |
| Control Interface | Front panel controls with digital metering display |
Pacific Power 312LMX Options:
- 312LMX - VIN: 100 - AC Input Voltage 100 VAC (1-Phase Input)
- 312LMX - VIN: 110 - AC Input Voltage 110 VAC (1-Phase Input)
- 312LMX - VIN: 120 - AC Input Voltage 120 VAC (1-Phase Input)
- 312LMX - VIN: 200 - AC Input Voltage 200 VAC (1-Phase Input)
- 312LMX - VIN: 230 - AC Input Voltage 230 VAC (1-Phase Input)
- 312LMX - VIN: 240 - AC Input Voltage 240 VAC (1-Phase Input)
- 312LMX - PPSC - PPSC Test Manager SW License
- 312LMX - AVIONICS/IEC - Avionics or IEC Test Sequences
- 312LMXTE - E - Export Version (for use outside of the USA)
| Model | 312LMX |
|---|
The Pacific Power 312LMX is a medium three-phase member of the LMX-Series, delivering low output voltage noise, minimal distortion, and superior waveform fidelity. With quartz-crystal stabilized output frequencies from 15 to 5,000 Hz, it ensures high stability and precision. Voltage ranges include up to 150VL-N in single-phase, 300VL-L in split-phase, and 259VL-L in three-phase mode, making it highly versatile for diverse testing needs.
Equipped with a powerful micro-controller, the 312LMX can operate as a fully integrated test system. It supports manual frequency conversion, harmonic testing, and programmable transient simulation, offering broad flexibility for research, development, and industrial applications.
Testwall can supply the used Pacific Power 312LMX, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Pacific Power 312LMX.
