Pendulum GSG-54 & 55
4 independent GNSS signal channels Number of Channels
GPS, GLONASS, Galileo, BeiDou Supported Constellations
L1, L2, L5 bands Frequency Range
-65 dBm to -120 dBm (adjustable) Output Power
< 0.001 ppm Frequency Accuracy
| Attribute | Value |
|---|---|
| Number of Channels | 4 independent GNSS signal channels |
| Supported Constellations | GPS, GLONASS, Galileo, BeiDou |
| Frequency Range | L1, L2, L5 bands |
| Output Power | -65 dBm to -120 dBm (adjustable) |
| Frequency Accuracy | < 0.001 ppm |
| Interface | Ethernet, USB, GPIB (IEEE 488) |
| Scenario Simulation | Real-time multi-constellation scenario simulation supported |
| Reference Input | 10 MHz external reference input |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Form Factor | Rackmount, 2U chassis |
Pendulum GSG-54 & 55 Options:
- GSG-55 - Option 40/54 - Ultra-high-stability OCXO instead of standard OCXO
- GSG-55 - Option 01/70 - Helix Antenna
- GSG-55 - Option 22/90 - Rack-mount kit
- GSG-55 - Option 27 - Soft carrying case
- GSG-55 - Option 27H - Heavy-duty hard transport case
- GSG-55 - Option 90/54 - Calibration Certificate with Protocol
- GSG-55 - Option 95/03 - Extended warranty to 3 years
- GSG-55 - Option 95/05 - Extended warranty to 5 years
- GSG-55 - OM-54 - Users manual (printed)
| Model | GSG-54 |
|---|
