Philips PM5696D
| Attribute | Value |
|---|---|
| Frequency Range | 1 Hz to 10 MHz |
| Output Waveforms | Sine, Square, Triangle, Pulse, Ramp |
| Output Amplitude | Up to 20 Vpp (into open circuit) |
| Output Impedance | 50 Ohms |
| Frequency Accuracy | ±0.01% (crystal controlled timebase) |
| Modulation Capabilities | AM, FM, and Sweep modulation supported |
| DC Offset | Adjustable ±10 V (into open circuit) |
| Display Type | LED frequency counter display |
| Power Supply | 115/230 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Model | PM5696D |
|---|
The Philips PM5696D is an advanced television signal generator, building upon the PM5696 with expanded digital capabilities. It features an extended test pattern library, improved stability, and enhanced digital functions to meet the rigorous demands of broadcast engineers. Its design supports multi-format television signals, making it an essential tool for precise signal evaluation across analog and early digital systems.
With user-friendly controls, the Philips PM5696D ensures quick setup and reliable long-term performance. Its versatile test signals are invaluable for calibration, troubleshooting, and system verification in professional broadcasting environments.
Testwall can supply the used Philips PM5696D, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Philips PM5696D.
